Pipe Flange Robotic Welding
Industry: Pipeline & Piping
Robotic welding of pipe-to-flange joints. The positioner rotates the pipe and flange so the robot welds the circumferential seam in the flat position, giving consistent penetration and bead shape across batches.
Typical equipment configuration
- Six-axis arc welding robot (SHRH / QJR / FANUC series)
- Welding power source matched to material and process (ESAB Aristo / Fabricator EM or partner brands)
- Positioner or ground track sized to the workpiece
- Dedicated or flexible welding fixtures
- Safety fencing and cell controls
Each workstation is configured to the customer's workpiece, cycle time and layout. Contact us with your drawings for a tailored proposal.
