Pressure Vessels & Boilers

Manipulators, rotators, seam welders, tube-sheet welders and cladding for vessels and boilers.

Industry Solution

Shell, head and tube-sheet welding automation

Pressure vessels, boilers, storage tanks and heat exchangers require code-quality longitudinal and circumferential seams, high-volume tube-to-tubesheet welds and corrosion-resistant overlays. Our column & boom manipulators, rotators, P+T seam welders and hot-wire TIG cladding systems cover the complete process.

Pressure Vessels & Boilers
Challenges

What manufacturers need

Long and circumferential seams

Shells up to φ4000 mm and 30 m long must be welded with constant quality.

Thousands of tube joints

Heat exchanger tube sheets require repeatable, documented TIG welds.

Corrosion-resistant layers

Bores and outer diameters need efficient stainless or nickel-alloy overlay.

Workpiece handling

Heavy shells must rotate smoothly and without axial drift.

Our Solution

Equipment configuration

  1. Manipulators & rotators

    Column & boom manipulators with gas-shielded or SAW power sources, self-aligning and adjustable rotators.

  2. Seam welding machines

    P+T circumferential (φ500–φ2300 mm) and longitudinal seam welders, combined machines up to φ4000 mm, BHLM gantry welders.

  3. Tube-sheet welding

    Automatic TIG tube-to-tubesheet welders (φ10–φ80 mm) and CNC/robotic tube-sheet welding with DXF import.

  4. Cladding

    Hot-wire TIG bore, outer-diameter and narrow-gap cladding with arc length tracking.

Recommended Equipment

Products for pressure vessel

Applications

Related application cases

TIG Welding Robot Workstation (1.4 m Arm)
Pipeline & Piping

Pipe Flange Robotic Welding

Robotic welding of pipe-to-flange joints. The positioner rotates the pipe and flange so the robot welds the circumferential seam in the flat…

Plan your pressure vessel welding line with our engineers

Send us your workpiece drawings, material, thickness and target output — we will propose a configuration and quotation.
